Or Out (OROUT)
The Or Out instruction allows more than one rung of discrete
230
logic to control a single output. Multiple Or Out instructions
240
referencing the same output coil may be used, since all
250-1
contacts controlling the output are logically ORed together. If
the status of any rung is on, the output will also be on.
260
Operand Data Type
Inputs
Outputs
Control Relays
Global
Global
In the following example, when X1 or X4 is on, Y2 will energize.
DS Used
DirectSOFT
HPP Used
X1
X4
Not (NOT)
230
The Not instruction inverts the status of the rung at
240
the point of the instruction.
250-1
260
In the following example when X1 is off, Y2 will energize. This is because the Not instruction
inverts the status of the rung at the Not instruction.
DirectSOFT
DS Used
X1
HPP Used
Chapter 5: Standard RLL Instructions - Boolean
DL230 Range DL240 Range DL250-1 Range DL260 Range
A aaa
X 0–177 0–477
Y 0-177
C 0–377 0–377
GX -
GY -
Handheld Programmer Keystrokes
Y2
$
STR
OR OUT
O
INST#
$
STR
Y2
O
INST#
OR OUT
Y2
OUT
