Automationdirect.com DirectLOGIC DL205 Series User Manual page 448

ECOM100 Configuration (ECOM100)
ECOM100 Disable DHCP (ECDHCPD)
ECOM100 Enable DHCP (ECDHCPE)
ECOM100 Query DHCP Setting (ECDHCPQ)
ECOM100 Send E-mail (ECEMAIL)
ECOM100 Restore Default E-mail Setup (ECEMRDS)
ECOM100 E-mail Setup (ECEMSUP)
ECOM100 IP Setup (ECIPSUP)
ECOM100 Read Description (ECRDDES)
ECOM100 Read Gateway Address (ECRDGWA)
ECOM100 Read IP Address (ECRDIP)
ECOM100 Read Module ID (ECRDMID)
ECOM100 Read Module Name (ECRDNAM)
ECOM100 Read Subnet Mask (ECRDSNM)
ECOM100 Write Description (ECWRDES)
ECOM100 Write Gateway Address (ECWRGWA)
ECOM100 Write IP Address (ECWRIP)
ECOM100 Write Module ID (ECWRMID)
ECOM100 Write Name (ECWRNAM)
ECOM100 Write Subnet Mask (ECWRSNM)
ECOM100 RX Network Read (ECRX)
ECOM100 WX Network Write(ECWX)
NETCFG Network Configuration (NETCFG)
Network RX Read (NETRX)
Network WX Write (NETWX)
Counter I/O IBoxes (Work with H2-CTRIO and H2-CTRIO2)
CTRIO Configuration (CTRIO)
CTRIO Add Entry to End of Preset Table (CTRADPT)
CTRIO Clear Preset Table (CTRCLRT)
CTRIO Edit Preset Table Entry (CTREDPT)
CTRIO Edit Preset Table Entry and Reload (CTREDRL)
CTRIO Initialize Preset Table (CTRINPT)
CTRIO Initialize Preset Table (CTRINTR)
CTRIO Load Profile (CTRLDPR)
CTRIO Read Error (CTRRDER)
CTRIO Run to Limit Mode (CTRRTLM)
CTRIO Run to Position Mode (CTRRTPM)
CTRIO Velocity Mode (CTRVELO)
CTRIO Write File to ROM (CTRWFTR)
NOTE: Check your CPU firmware version using DirectSOFT: PLC Menu > Diagnostics > System
Information. The latest firmware and update tool are available from:
http://support.automationdirect.com/firmware/index.html
Chapter 5: Intelligent Box (IBox) Instructions
Communication IBoxes
Instruction
Instruction
DL205 User Manual, 4th Edition, Rev. B
Ibox # Page
IB-710 5-272
IB-736 5-274
IB-735 5-276
IB-734 5-278
IB-711 5-280
IB-713 5-283
IB-712 5-286
IB-717 5-290
IB-726 5-292
IB-730 5-294
IB-722 5-296
IB-720 5-298
IB-724 5-300
IB-732 5-302
IB-727 5-304
IB-731 5-306
IB-723 5-308
IB-721 5-310
IB-725 5-312
IB-733 5-314
IB-740 5-316
IB-741 5-319
IB-700 5-322
IB-701 5-324
IB-702 5-327
Ibox # Page
IB-1000 5-330
IB-1005 5-332
IB-1007 5-335
IB-1003 5-338
IB-1002 5-342
IB-1004 5-346
IB-1010 5-350
IB-1001 5-354
IB-1014 5-357
IB-1011 5-359
IB-1012 5-362
IB-1013 5-365
IB-1006 5-368
