ECOM100 Restore Default E-mail Setup (ECEMRDS) (IB-713)
ECOM100 Restore Default EMail Setup, on a leading edge transition, will restore the
original EMail Setup data stored in the ECOM100 back to the working copy based on the
230
specified ECOM100#, which corresponds
to a specific unique ECOM100
240
Configuration (ECOM100) at the top of
250-1
your program.
260
When the ECOM100 is first powered up, it
copies the EMail setup data stored in ROM
DS5
Used
to the working copy in RAM. You can then
N/A
HPP
modify this working copy from your
program using the ECOM100 EMail Setup
(ECEMSUP) IBox. After modifying the
working copy, you can later restore the
original setup data via your program by
using this IBox.
The Workspace parameter is an internal, private register used by this IBox and MUST BE
UNIQUE in this one instruction and MUST NOT be used anywhere else in your program.
Either the Success or Error bit parameter will turn on once the command is complete. If there
is an error, the Error Code parameter will report an ECOM100 error code (less than 100), or
a PLC logic error (greater than 1000).
In order for this ECOM100 IBox to function, you must turn ON dip switch 7 on the
ECOM100 circuit board.
ECEMRDS Parameters
• ECOM100#: this is a logical number associated with this specific ECOM100 module in the
specified slot. All other ECxxxx IBoxes that need to reference this ECOM100 module must
reference this logical number
• Workspace: specifies a V-memory location that will be used by the instruction
• Success: specifies a bit that will turn on once the request is completed successfully
• Error: specifies a bit that will turn on if the instruction is not successfully completed
• Error Code: specifies the location where the Error Code will be written
ECOM100# . . . . . . . . . . . . . . . . . . . . . . . . . . . . K
Workspace . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Success . . . . . . . . . . . . . . . . . . . . X,Y,C,GX,GY,B
Error . . . . . . . . . . . . . . . . . . . . . . . X,Y,C,GX,GY,B
Error Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Parameter
Chapter 5: Intelligent Box (IBox) Instructions
DL205 Range
K0-255
See DL205 V-memory map - Data Words
See DL205 V-memory map
See DL205 V-memory map
See DL205 V-memory map - Data Words
DL205 User Manual, 4th Edition, Rev. B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
5–283
