Chapter 5: Standard RLL Instructions - Math
Multiply (MUL)
1
Multiply is a 16-bit instruction that multiplies the BCD
230
value (Aaaa), which is either a V-memory location or a
240
4–digit (max.) constant, by the BCD value in the lower 16
2
250-1
bits of the accumulator The result can be up to 8 digits and
resides in the accumulator.
260
3
Operand Data Type
4
V-memory
Pointer
5
Constant
6
Discrete Bit Flags
SP63
SP70
7
SP75
NOTE: The status flags are only valid until another instruction that uses the same flags is executed.
8
In the following example, when X1 is on, the value in V2000 will be loaded into the
9
accumulator using the Load instruction. The value in V2006 is multiplied by the value in the
accumulator. The value in the accumulator is copied to V2010 and V2011 using the Out
Double instruction.
10
DS Used
11
HPP Used
12
13
14
A
B
C
D
