Chapter 5: Intelligent Box (IBox) Instructions
Analog Input/Output Combo Module Pointer Setup (ANLGCMB) (IB-462)
1
The Analog Input/Output Combo Module Pointer Setup instruction generates the logic to
configure the pointer method for an analog input/output combination module on the first
230
PLC scan following a Program to Run transition.
2
240
The ANLGCMB IBox instruction
250-1
determines the data format and Pointer
3
260
addresses based on the CPU type, the
Base# and the module Slot#.
4
DS5 Used
The Input Data Address is the starting
N/A
HPP
location in user V-memory where the
5
analog input data values will be stored,
one location for each input channel
enabled.
6
The Output Data Address is the starting
location in user V-memory where the
7
analog output data values will be stored
by ladder code or external device, one location for each output channel enabled.
8
Since the IBox logic only executes on the first scan, the instruction cannot have any input logic.
9
ANLGCMB Parameters
• Base # (K0-Local): specifies which base the module is in
10
• Slot #: specifies which slot is occupied by the analog module
• Number of Input Channels: specifies the number of analog input channels to scan
11
• Input Data Format (0-BCD 1-BIN): specifies the analog input data format (BCD or Binary) - the
binary format may be used for displaying data on some OI panels
12
• Input Data Address: specifies the starting V-memory location that will be used to store the analog
input data
13 • Number of Output Channels: specifies the number of analog output channels that will be used
• Output Data Format (0-BCD 1-BIN): specifies the format of the analog output data (BCD or
Binary)
14
• Output Data Address: specifies the starting V-memory location that will be used to source the
analog output data
A
NOTE The ANLGCMB instruction does not currently support the F2-8AD4DA-1 or
F2-8AD4DA-2.
