Operating Your Video Matrix Switcher; Startup Display - Kramer VS-3232DN-EM User Manual

Operating Your Video Matrix
Switcher
This section describes:
•
The startup display (see
•
Using the selector buttons (see
•
Confirming actions (see
•
Switching options (see
•
Locking the front panel (see

Startup Display

After switching on the power, the LCD display shows the following screens in sequence (text
in the LCD Display may vary according to machine settings).
The VS-3232DN-EM
panel includes a numeric keypad within the Selector Buttons area (see
VS-3232DN-EM 4x4 to 32x32 Modular Multi-Format Managed Digital Matrix
Switcher on page 7). This numeric keypad lets you enter both the output and input numbers
as well as various numeric configuration values (see
When the unit is powered-on, the last matrix setup that was used is loaded. Use either the
setup recall (records a stored configuration from a preset, see
XX, Recalling a Preset
used programmable default setup, see
retrieve other setups.
Viewing the Display
Figure 11 shows the output-input matrix on the LCD display. The LCD display can show 13
out of the 32 available matrix combinations at once. To view any of the matrix combinations
use the ◄ or the ► buttons on the front panel to shift the display to the right or left.
VS-3232DN-EM – Operating Your Video Matrix Switcher
Startup Display
Using the Selector Buttons
Confirming Actions
Switching Actions
Locking the Front Panel Buttons
Figure 11: Default Startup Status Display Sequence
does not have separate output and input buttons. Instead, the front
on page 28) or default setup recall (for quick retrieval of a commonly
Recalling the Default Setup
on page 19).
on page 20).
on page 20).
on page 21).
on page 23).
Using the Selector Buttons
Setup Menu—6: recall setup
on page 23) functions to
