Protocol 3000 - Kramer VS-3232DN-EM User Manual

Protocol 3000

The VS-3232DN-EM 4x4 to 32x32 Modular Multi-Format Managed Digital Matrix Switcher
can be operated using the Kramer Protocol 3000 serial commands. The command framing
varies according to how you interface with the VS-3232DN-EM. For example, a basic video
input switching command that routes a layer 1 video signal to HDBT out 1 from HDMI input 2
(ROUTE 1,1,2), is entered as follows:
•
Terminal communication software, such as Hercules:
The framing of the command varies according to the terminal communication software.
•
K-Touch Builder (Kramer software):
•
K-Config (Kramer configuration software):
All the examples provided in this section are based on using the K-Config software.
You can enter commands directly using terminal communication software (e.g., Hercules) by
connecting a PC to the serial or Ethernet port, depending on your device. To enter CR press
the Enter key (LF is also sent but is ignored by the command parser).
Commands sent from various non-Kramer controllers (e.g., Crestron) may require special
coding for some characters (such as, /X##). For more information, refer to your controller's
documentation.
For more information about:
•
Understanding Protocol 3000 commands (see
VS-3232DN-EM – Protocol 3000
Understanding Protocol 3000
