VGAA-IN4-F32 Input Card
Parameter Description
Phase (0–63)
adjustment
Note: This adjustment is only valid when Phase Mode Is set to User
Defined mode.
Reset Input
Re-power—Power cycles the port.
Factory—Performs a factory reset of the port to default values.
Hor-Total Pixels Set the value for total horizontal pictures.
(1–7000)
Horizontal-Start Set the value for horizontal start.
(1–600)
Horizontal- Set the value for horizontal active pixels.
Active
(1–4000)
Vertical-Start Set the value for vertical start.
(1–255)
Vertical-Active Set the value for vertical active pixels.
(1–3000)
Save Timing (0–31)
Para
Recall Timing (0–31)
Para
Volume Sets the audio output volume (0–70).
Audio Balance Sets the audio output channel balance (0–100).
Audio Bass Sets the audio output bass level (0–15).
Audio Treble Sets the audio output treble level (0–15).
Audio Mute MUTE—Mutes the audio input.
Non-MUTE—Unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
R-offset (0–63)
G-offset (0–63)
B-offset (0–63)
R-gain (0–63)
G-gain (0–63)
B-gain (0–63)
The Auto Adjust feature requires the device to recalculate the parameters based on the
currently connected source. The result may be different from the standard parameters for the
currently set resolution. The result is saved in non-volatile memory and is recalled when the
same source is used again. In order to revert to auto predefined parameters, either reset to
factory setting with the relevant source connected or connect a different source.
The VGAA-OUT4-F32 configuration table appears as follows:
VGAA-OUT4-F32 Output Card
Parameter Description
Reset Output Re-power: power cycles the port.
Factory: performs a factory reset of the port to default values.
Switch Speed When switching between different sources the switching time can be
reduced by setting the fast switch level (Ex-fast Switch, Fast Switch or
Normal Switch).
Volume Sets the audio output volume (0–70).
Audio Balance Sets the audio output channel balance (0–100).
Audio Bass Sets the audio output bass level (0–15).
VS-3232DN-EM – Using the Input / Output Cards
Kramer Electronics Ltd.
Default
As
detected
-
As
detected
As
detected
As
detected
As
detected
As
detected
N/A
N/A
50
50
7
7
Non-
MUTE
32
32
32
32
32
32
Default
-
Normal
Switch
50
50
7
65
