2. Press ENT.
The following is displayed:
Test Board: 0
where 0 indicates that the test module is not installed.
3. Using the numeric keys, press 1 to indicate that the test module is installed.
The TAKE button flashes.
4. Press TAKE.
5. Increase the number of configured inputs and outputs by one (see
Number of Installed Input and Output Ports
6. Power cycle the device.
The test module is now installed and may be used.
VS-3232DN-EM – Using the Test Video Card
MaxInput:32
MaxOutput:32
on page 35).
Kramer Electronics Ltd.
Configuring the
38
