The HAA-OUT4-F32 configuration table appears as follows:
HAA-OUT4-F32 Output Card
Parameter Description
Switch When switching between different sources the switching time can be reduced
Speed by setting the fast switch level (Ex-fast Switch, Fast Switch or Normal
Switch).
Volume Sets the audio output volume (0–70).
Note: Not applicable when digital audio is selected.
Audio Sets the audio output channel balance (0–100).
Balance
Note: Not applicable when digital audio is selected.
Audio Bass Sets the audio output bass level (0–15).
Note: Not applicable when digital audio is selected.
Audio Sets the audio output treble level (0–15).
Treble
Note: Not applicable when digital audio is selected.
Audio Mono OFF—Analog output is stereo.
MIX—Analog output is mono.
Note: Not applicable when digital audio is selected.
Audio Mute MUTE—Mutes the audio input.
Non-MUTE—Unmutes the audio input.
Note: When set to Mute, any change to the audio parameters automatically
sets this to unmute.
Note: Not applicable when digital audio is selected.
HDMI Sets the output signal format (Display, HDMI, DVI).
Display—the output is set automatically based on the EDID of the connected
display.
HDMI—Force the output to be HDMI.
DVI—Force the output to be DVI.
Note: When selecting the DVI option and fast switching is enabled, you must
ensure that the source is DVI compatible.
Deep Color Sets maximum color bit depth (Auto, 8 bit).
Auto—Set the color depth automatically.
8 bit—Limit the color depth to 8 bits.
Reset Re-power—Power cycles the port.
Output
Factory—Performs a factory reset to default values of the port.
HAA-IN4-F32 / HAA-OUT4-F32 Technical Specifications
The following table defines the technical specifications.
PORTS:
BANDWIDTH PER CHANNEL:
TOTAL BANDWIDTH:
MAXIMUM RANGE:
3D PASS THROUGH:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
PRODUCT WEIGHT:
VS-3232DN-EM – Using the Input / Output Cards
4 HDMI
4 Analog audio on 3.5mm mini jacks
2.25Gbps
6.75Gbps
15m (49ft)
Supported
Input card: 11W
Output card: 12W
0° to +40°C (32° to 104°F)
–40° to +70°C (–40° to 158°F)
10% to 90%, RHL non-condensing
22cm x 18.8cm x 2cm (8.7" x 7.4" x 0.8") W, D, H
0.28 kg (0.62 lbs) approx.
Kramer Electronics Ltd.
Default
Normal
Switch
50
50
7
7
OFF
Non-
MUTE
Display
Auto
-
