Connecting the VS-3232DN-EM

Always switch off the power to each device before connecting it to your VS-3232DN-EM. After
connecting your VS-3232DN-EM, connect its power and then switch on the power to each
device.
You do not have to connect all the inputs and outputs, connect only those that are required. In
the following example, only two inputs and two outputs are connected.
The configuration of DVI input/output cards shown in
representation and different input / output cards may be mixed as required (for limitations, see
Port Numbering on page 14). Exactly the same principles apply to installations using other
card types.
To connect the VS-3232DN-EM, as illustrated in the example in
1. Connect up to 32 DVI video sources (for example, computer graphics sources).
2. Connect up to 32 DVI video acceptors, (for example, a DVI display and a DVI LCD
display).
3. If required, connect a PC or remote controller to the RS-232 port (see
VS-3232DN-EM via RS-232
VS-3232DN-EM via Ethernet
4. Connect the power cord.
5. If necessary, review and set the system configuration using the Menu (see
Configuration Menus
Given an input signal that is HDCP encoded, the
output port to which it is switched supports HDCP.
VS-3232DN-EM – Connecting the VS-3232DN-EM
on page 15) and/or the Ethernet port (see
on page 16).
on page 24).
Figure 4 is merely a sample
Figure 4, do the following:
VS-3232DN-EM outputs a signal only if the
Kramer Electronics Ltd.
Connecting to the
Connecting to the
Using the
12
