Testing the Output Signal Path to the Projector
Signal path: a to b; b to projector
To test the output signal path to the projector:
1. Configure Input 33 to Output 1 (see
2. Connect Output 1 to the projector.
3. Set the generated video resolution (see
Video
on page 36).
4. Set the pattern for the generated video (see
Video
on page 37).
5. Verify that the projector output is as expected.
Testing the Input and Output Signal Path to the
Projector
Signal path: c to e; e to f; f to b; b to projector.
To test the input and output signal path to the projector:
1. Configure Input 33 to Output 33 (see
2. Connect Output 33 to Input 1.
3. Configure Input 1 to Output 1.
4. Connect Output 1 to the projector.
5. Set the generated video resolution (see
Video
on page 36).
6. Set the pattern for the generated video (see
Video
on page 37).
7. Verify that the projector output is as expected.
VS-3232DN-EM – Using the Test Module to Troubleshoot Video Problems
Switching Actions
on page 21).
Setting the Resolution of the Generated
Setting the Pattern of the Generated
Switching Actions
on page 21).
Setting the Resolution of the Generated
Setting the Pattern of the Generated
Kramer Electronics Ltd.
70
