CPEDID
Functions
CPEDID
Set
Get -
Description
Copy EDID data from the output to the input
Set EEPROM
Get -
Response
~nn@CPEDIDSPoutput_id,input_idCR LF
Parameters
output_id – video output ID: 1-32 (varies according to installed output cards, see
Numbering on page 14)
input_id – video input ID: 1-32 (varies according to installed input cards, see
Numbering on page 14)
Response Trigger
Response is sent to the com port from which the Set was received (before execution)
Notes
K-Config Example
Copy the EDID data from output 8 to input 1:
"#CPEDID 8,1,0x1",0x0D
GEDID
Functions
GEDID
Set
Get -
Description
Read EDID data from device
Set
Get -
Response
Multi-line response:
~nn@GEDIDSPeeprom_id,sizeCR LF
Edid_dataCR LF
~nn@GEDIDSPeeprom_idSPOKCR LF
Parameters
eeprom_id – Input port EEPROM ID from which to get the EDID: 1-32 (varies according to installed
input cards, see Port Numbering
size – EDID data size sent from the device
Edid_data – EDID data, as byte stream
Response Trigger
Response is sent to the com port from which the Set (before execution) command was received
Notes
K-Config Example
Read EDID data from a device connected to Input 1:
"#GEDID 1",0x0D
VS-3232DN-EM – Protocol 3000
Permission
End User
-
Syntax
#GEDIDSPeeprom_idCR
-
on page 14)
Permission Transparency
End User Public
- -
Syntax
#CPEDIDSPoutput_id,input_idCR
-
Port
Port
Transparency
Public
-
