Installing a PS-1DN Power Supply

The VS-3232DN-EM
optional redundant power supply for mission critical installations. When two power supplies
are installed, the
recommends using two power supply units for extending power supply life-span.
The PS-1DN is a hot-swappable power supply. It is not necessary to power down the chassis
in order to install or replace a second power supply.
When installing/replacing a power supply, all normal static discharge precaution measures
must be observed to prevent damage to the equipment.
For detailed instructions on installing/replacing a power supply in your VS-3232DN-EM, see
the PS-1DN Power Supply Installation Instructions, available at www.kramerav.com.
The following table describes the behavior of the power supply LEDs:
Event Green POWER LED
Device power Lights and remains on
on
Device power Remains on for ~20 seconds and then turns
off off
If no LEDs light, verify the following:
•
The power supply connector at the rear of the device is connected to the mains power
supply (see
Digital Matrix Switcher
•
The power switch is switched to the On position.
•
The power supply is seated firmly in place – the front panel of the power supply is flush
with the front panel of the chassis and the screws are tightly fastened.
If the problem persists, or if the red ERROR LED is always lit, contact Kramer technical
support.
VS-3232DN-EM – Installing a PS-1DN Power Supply
is equipped with a single PS-1DN power supply unit and includes an
VS-3232DN-EM distributes the load between the power supplies. Kramer
Defining the VS-3232DN-EM 4x4 to 32x32 Modular Multi-Format Managed
on page 7).
Kramer Electronics Ltd.
Red ERROR LED
Lights for a few seconds and turns off
Lights for ~20 seconds and then turns
off
