Kramer VS-3232DN-EM User Manual page 117

VID
Functions
VID
Set
VID?
Get
Description
Set video switch state
Set
Get
Get video switch state
Response
~nn@VIDSPin>outCR LF
Set:
~nn@VIDSPin>outCR LF ...
~nn@VIDSPin>outCR LF
Get:
~nn@VIDSPin>1,in>2,...CR LF
Parameters
in – input number: 0 (if output disconnected), 1-32 (varies according to installed input cards, see
Numbering on page 14)
> – connection character between in and out parameters
out – output number: 1-32 (varies according to installed output cards, see
* (all outputs)
Response Trigger
Notes
When AFV switching mode is active, this command also switches audio and the unit replies with
command ~AV.
Examples
Switch video input 2 to output 4
Switch video input 4 to output 2 in
machine 6
Switch video input 3 to all outputs
Chaining multiple
commands
K-Config Example
Set the video switch state from input 4 to output 2:
"#VID 4>2",0x0D
VS-3232DN-EM – Protocol 3000
Permission
End User
End User
Syntax
#VIDSPin>out,in>out,...CR
#VID?SPoutCR
#VID?SP*CR
#V 2>4CR
#6@VID 4>2CR
#V 3>*CR
#AV 1>* | V 3>4,2>2,2>1,0>2 | V
3>9| A 0>1 | V? *CR
1. Switch audio and video from input 1 to all
outputs
2. Switch video input 3 to output 4,
video input 2 to output 2,
video input 2 to output 1 and
disconnect video output 2
3. Switch video input 3 to output 9 (non-
existent)
4. Disconnect audio output 1
5. Get status of all video links
Command processing begins after entering
CR
A response is sent for each command after
processing
Kramer Electronics Ltd.
Transparency
Public
Public
Port Numbering on page 14),
~01@VID 2>4CRLF
~06@VID 4>2CRLF
~01@VID 3>*CRLF
~AV 1>*CRLF
~VID 3>4 CRLF
~VID 2>2 CRLF
~VID 2>1 CRLF
~VID 0>2 CRLF
~VID ERR003 CRLF
~AUD 0>1CRLF
~VID 2>1,0>2,1>3,
3>4CRLF
Port
114
