Using the Configuration Menus

The configuration menus let you configure the
are two configuration menus:
•
Setup Menu—those that are accessed on a regular basis (for example, storing setups
and setting the delay), see
•
Config Menu—those that are accessed only occasionally (for example, setting the
interface or communication protocol), see
The following rules apply to the menu operation:
•
If no selection is made within approximately 15 seconds, the operation times-out and the
display reverts to the output/input display.
•
At any point in the Menu, press ESC to move up one level or press BREAKAWAY to exit
the Menu altogether.
•
At any point in the Menu, only buttons that are active light or flash.
All the procedures in this section assume that you are starting the procedure from the
standard, operational output/input display.

Using the Setup Menu

The Setup Menu provides access to settings that are regularly changed and comprises the
following options:
•
1: inXX=>ALL, switching one input to all outputs (see
Switching One Input to all Outputs
•
3: outXX=OFF, turning off an output (see
Output Off on page 25).
•
7: EDID, assignment to an output (see
Input on page 26).
•
9: Delay setting for an output (see
Output on page 27).
•
4: store setup XX, storing the setup in a preset (see
Storing the Setup in a Preset
•
6: recall setup XX, recalling a preset (see
Preset on page 28).
VS-3232DN-EM – Using the Configuration Menus
VS-3232DN-EM
Using the Setup Menu
Using the Config Menu
on page 25).
Setup Menu—3: outXX=>OFF, Turning an
Setup Menu—7: EDID, Assignment to an
Setup Menu—9: Delay, Setting for an
on page 27).
Setup Menu—6: recall setup XX, Recalling a
Kramer Electronics Ltd.
to best suit your needs. There
on page 24.
on page 28.
Setup Menu—1: inXX=>ALL,
Setup Menu—4: store setup XX,
