The VS-3232DN-EM
•
Full 32 x 32 non-blocking matrix array to switch any of the 32 input digital signals to any
or all outputs (see
•
Easy access to 59 pre-set memory locations for quick access to user-defined setups.
•
Fast switching on outputs to reduce or remove switching delay.
•
Redundant, hot swappable power supply (optional).
•
Simple firmware upgrade of compatible devices (see
Firmware on page 74).
•
Seamless integration with Kramer Network for switching, card status, port status,
firmware upgrades (of compatible cards), and more.
•
A 40 character by 2 line LCD that shows the operational status or the configuration
menu.
•
A lock function to prevent tampering with the front panel.
•
A default EDID (Extended Display Identification Data) for each input.
•
Non-volatile EDID storage.
•
Kramer Core™ – Flexible infrastructure conversion. Copper, fiber or Twisted Pair, all can
be used at the same time according to input/output module selection. The matrix
receives signals from compatible Kramer transmitters, automatically converts between
available infrastructure options and sends the signals to compatible Kramer receivers.
•
Max. Data Rate – 10.2Gbps (3.4Gbps per graphic channel) when using compatible
cards.
•
HDTV Compatible.
•
HDCP Compliant – With DVI (HDCP), HDMI, F670, HDBaseT, HDMI with audio and
DGKat modules.
•
HDMI Support.
•
DGKat™ Signal Integration – Kramer's unique technology for converting TMDS as well
as control and communication to signals that run over twisted pair cables. For optimum
range and performance using, use recommended Kramer cables, available at:
www.kramerav.com/product/VS-3232DN-EM
•
Kramer Equalization & re-Klocking™ Technology – Rebuilds the digital signal to travel
longer distances.
•
Optional Fast Switching Support – For fraction of a second switching.
•
Modular & Easily Configurable Platform – Input or output module types can be mixed
and added in increments of 4 from 4x4 up to 32x32.
•
Versatile Selection of Modules – Including DVI, HDMI, HDCP (HDMI over DVI
connector), Dual Link DVI, HDMI over Fiber, DVI over Fiber, HDBaseT, HDMI with
analog audio interface, HDMI with digital audio interface, VGA and DGKat (HDMI over
twisted pair).
•
Kramer Protocol 3000 Support.
•
Flexible Configuration – To disable HDCP support and convert between HDMI and DVI.
VS-3232DN-EM – Introduction
features:
Connecting the VS-3232DN-EM
Kramer Electronics Ltd.
on page 11).
Upgrading the VS-3232DN-EM
5
