Input / Output Card Hardware
Installation Instructions
The
VS-3232DN-EM
VS-3232DN-EM
cards is the same for all cards / chassis and the figures below are for illustration purposes
only.)
An input card must only be mounted in a slot designated for input cards (slots IN 1 to 16 and
IN 17 to 32) and an output card must only be mounted in a slot designated for output cards
(slots OUT 1 to 16 and OUT 17 to 32).
To install an input / output card as shown in
1. Power off the
2. Using a Phillips screwdriver, loosen the screws at the top and bottom of the blanking
plate (see
Figure
VS-3232DN-EM – Input / Output Card Hardware Installation Instructions
input / output cards mount in one of the 16 slots on the rear of the
chassis. Slots are numbered from left to right. (The process for inserting
Figure 17: Inserting the Card into a Slot
VS-3232DN-EM
and all devices connected to it.
18).
Figure
17:
Kramer Electronics Ltd.
71
