Config Menu—Output Load Detection Display
This option displays a list of outputs and indicates which have loads attached to them.
To display a list of outputs and attached loads:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU until the following is displayed:
OUT:
LOAD:
o indicates that a load is attached and X indicates that no load is detected on the relevant
output.
3. Do one of the following:
▪
Press BREAKAWAY to exit the Config Menu.
▪
Wait approximately 15 seconds for the operation to time out.
▪
Press MENU to move to the next Config Menu option.
Config Menu—Setting Output Port Parameters
This option sets port-specific parameters. Ports that show an X have no parameters available
to modify. Ports that show an o have parameters available to modify. The parameters that are
available, such as, audio balance, depend on the type of card installed and whether the card
is an input or an output card (see
on the input / output cards and their parameters).
To set parameters for a port:
1. Press MENU twice.
The following message is displayed:
start configuration menu
MENU to view setup ENT to change them
2. Press MENU until a display is shown similar to the following:
OUT:
SET:
X indicates that there are no modifiable parameters for the associated port and o indicates
that there are modifiable parameters for the associated port.
3. Press TAKE to enter the list of ports.
The cursor flashes on a selected port.
4. Select the required port to modify using the left and right arrow buttons.
VS-3232DN-EM – Using the Configuration Menus
01
02
03
04
o
X
o
o
Using the Input / Output Cards
01
02
03
04
o
o
X
X
05
06
07
08
o
o
X
o
05
06
07
08
o
o
o
o
Kramer Electronics Ltd.
09
10
11
o
o
X
on page
39
for information
09
10
11
X
X
X
31
