HDBT-IN4-F32 / HDBT-OUT4-F32 Configuration
The HDBT-IN4-F32 configuration table appears as follows:
HDBT-IN4-F32 Input Card
Parameter Description
HDCP Turn HDCP on and off.
*0=EN, 1=DIS.
XTRA Enables range extender. Off for distances of up to 130m at 1080p @60Hz
@36bpp; On for distances of up to 180m at 1080p @60Hz @24bpp.
*0:ON, 1:OFF.
Note: Distances are valid when using Kramer BC-UNIKAT cables.
The HDBT-OUT4-F32 configuration table appears as follows:
HDBT-OUT4-F32 Output Card
Parameter Description
HDMI Sets the output signal format (Display, HDMI, DVI).
Display—the output is set automatically based on the EDID of the connected
display.
HDMI—Force the output to be HDMI.
DVI—Force the output to be DVI.
Note: When selecting the DVI option and fast switching is enabled, you must
ensure that the source is DVI compatible.
Deep Color Sets maximum color bit depth (Auto, 8 bit).
Auto—Set the color depth automatically.
8 bit—Limit the color depth to 8 bits.
Switch When switching between different sources the switching time can be reduced
Speed by setting the fast switch level (Ex-fast Switch, Fast Switch or Normal Switch).
XTRA Enables range extender. Off for distances of up to 130m at 1080p @60Hz
@36bpp; On for distances of up to 180m at 1080p @60Hz @24bpp.
*0:ON, 1:OFF.
Note: Distances are valid when using Kramer BC-UNIKAT cables.
HDBT-IN4-F32 / HDBT-OUT4-F32 Technical Specifications
HDBT cards must be used with twisted pair cables with RJ-45 connections, such as Kramer
BC-UNIKAT shielded twisted pair (U/FTP) cables.
The following table defines the technical specifications.
PORTS:
BANDWIDTH PER CHANNEL:
TOTAL BANDWIDTH:
MAXIMUM RANGE:
3D PASS THROUGH:
VS-3232DN-EM – Using the Input / Output Cards
4 HDBaseT TP on RJ45 connectors
4 RS-232 Serial ports and 4 IR ports on a 10-pin
terminal block
1 Ethernet port on an RJ-45 connector
Video: 2.25Gbps
Serial Data: 115200
Video: 6.75Gbps
Serial Data: 115200
130m (430ft) normal mode
180m (590ft) ultra-mode (1080p @60Hz @24bpp) when
using
BC-UNIKAT cables
Supported
