LDEDID
Functions
LDEDID
Set
Get -
Description
Write EDID data from external application
Set to device
Get -
Response
Step 1: #LDEDIDSPeeprom_ID,sizeCR
Response 1: ~nn@LDEDIDSPeeprom_id,sizeSPREADYCR LF or ~nn@LDEDIDSPERRnnCR LF
Step 2: If READY was received, send EDID_DATA
Response 2: ~nn@LDEDIDSPeeprom_id,sizeSPOKCR LF
Parameters
eeprom_id – Input port EEPROM destination for the EDID data: 1-32 (varies according to installed input
cards, see Port Numbering
size – EDID data size
EDID_DATA – HEX or KFW file in protocol packets (see
Response Trigger
Response is sent to the com port from which the Set (before execution) command was received
Notes
When the unit receives the LDEDID command it replies with READY and enters the special EDID packet
wait mode. In this mode the unit can receive only packets and not regular protocol commands.
If the unit does not receive correct packets for 30 seconds or is interrupted for more than 30 seconds
before receiving all packets, it sends timeout error ~nn@LDEDIDSPERR01CR LF and returns to the
regular protocol mode. If the unit received data that is not a correct packet, it sends the corresponding
error and returns to the regular protocol mode.
K-Config Example
Write EDID data from external application to Input 1:
"#LDEDID 1,256",0x0D
LOCK-FP
Functions
LOCK-FP
Set
LOCK-FP?
Get
Description
Lock front panel
Set
Get
Get front panel lock state
Response
Set: ~nn@LOCK-FPSPlock_modeSPOKCR LF
Get: ~nn@LOCK-FPSPlock_modeCR LF
Parameters
lock_mode – 0/OFF (unlocks the front panel buttons), 1/ON (locks the front panel buttons)
Response Trigger
Notes
K-Config Example
Lock the front panel of the VS-3232DN-EM:
"#LOCK-FP 1",0x0D
VS-3232DN-EM – Protocol 3000
on page 14)
Permission
End User
-
Syntax
Multi-step syntax (see following steps)
-
Using the Packet Protocol
Permission
End User
End User
Syntax
#LOCK-FPSPlock_modeCR
#LOCK-FP?CR
