VGAA-OUT4-F32 Output Card
Parameter Description
Audio Treble Sets the audio output treble level (0–15).
Audio Mute MUTE: mutes the audio input.
Non-MUTE: unmutes the audio input.
Note: When set to Mute, any change to the audio parameters
automatically sets this to unmute.
OUT_HSYNC_ Sets the H_SYNC invert.
INVERT (0, 1)
OUT_VSYNC_ Sets the V_SYNC invert.
INVERT (0, 1)
VGAA-IN4-F32 / VGAA-OUT4-F32 Technical Specifications
The following table defines the technical specifications.
PORTS:
BANDWIDTH:
MAXIMUM RANGE:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
PRODUCT WEIGHT:
SHIPPING WEIGHT:
STANDARD COMPLIANCE:
SAFETY REGULATORY
COMPLIANCE:
ENVIRONMENTAL REGULATORY
COMPLIANCE:
INCLUDED ACCESSORIES:
VS-3232DN-EM – Using the Input / Output Cards
4 VGA on 15-pin HD connectors
4 unbalanced analog audio on 3.5mm mini jack connectors
(accessible via C-GF/GMAF-30 cables)
450MHz
10m (32ft)
Input card: 18W
Output card: 9W
0° to +40°C (32° to 104°F)
–40° to +70°C (–40° to 158°F)
10% to 90%, RHL non-condensing
22cm x 18.8cm x 2cm (8.7" x 7.4" x 0.8") W, D, H
0.25 kg (0.55 lbs) approx.
0.42 kg (0.93 lbs) approx.
-
CE
Complies with appropriate requirements of RoHs and WEEE
4 C-GF/GMAF-30 cables
Kramer Electronics Ltd.
Default
7
Non-
MUTE
0
0
