Technical Specifications

VS-3232DN-EM Chassis

BANDWIDTH:
CONTROLS:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
COOLING:
ENCLOSURE TYPE:
RACK MOUNT:
DIMENSIONS:
SHIPPING DIMENSIONS:
PRODUCT WEIGHT:
SHIPPING WEIGHT:
VIBRATION:
SAFETY REGULATORY COMPLIANCE:
ENVIRONMENTAL REGULATORY
COMPLIANCE:
INCLUDED ACCESSORIES:
Specifications are subject to change without notice at

Quick VS-3232DN-EM Card Comparison

Card Ports
UHD 4 HDMI
UHDA 4 HDMI
4 Analog audio on
3.5mm mini jacks
DT 4 HDBaseT TP on RJ45
connectors
4 RS-232 Serial and 4
IR on 10-pin terminal
blocks
VS-3232DN-EM – Technical Specifications
Supports up to 3.4Gbps bandwidth per channel (limited by
the card installed)
Front panel buttons, Infrared remote control transmitter, RS-
232, Ethernet
100-240V AC, 50/60Hz, 3.7A
0° to +55°C (32° to 131°F)
–45° to +72°C (–49° to 162°F)
10% to 90%, RHL non-condensing
Forced air, fan
Aluminum
With supplied rack ears
19" 6U (48.3cm x 36cm x 26.6cm W, D, H)
60cm x 49.3cm x 39cm
13.54kg (29.85lbs) approx.
14.9kg (32.85lbs) approx.
ISTA 1A in carton (International Safe Transit Association)
CE
Complies with appropriate requirements of RoHs and
WEEE
Power cord, Infrared remote control transmitter
www.kramerav.com
BW per Max. Range
Channel
10m (32ft) –
2.97Gbps
4K60 4:2:0 or
4K30 4:4:4
15m (49ft) –
1080p 12 bit
(deep color)
10m (32ft) –
2.97Gbps
4K60 4:2:0 or
4K30 4:4:4
15m (49ft) –
1080p 12 bit
(deep color)
40m (130ft) – 4K
Vid: 3.4Gbps
@60Hz 4:2:0
Serial: 115200
or 4K @30Hz
4:4:4
70m (230ft) –
1080p 12 bit
(deep color)
Kramer Electronics Ltd.
Compliance 3D
Pass
Thru
HDCP 1.4, Yes
HDMI 1.4,
HDTV
compatible
HDCP 1.4, Yes
HDMI 1.4,
HDTV
compatible
HDCP 1.4, Yes
HDMI 1.3a,
HDBaseT,
HDTV
compatible
