DETAIL-TIMING
Functions
DETAIL-TIMING
Set
DETAIL-TIMING?
Get
Description
Set detailed timing
Set
parameters
Get
Get detailed timing
parameters
Response
~nn@DETAIL-TIMINGSPparam,channel,valueCR LF
Parameters
param – 1 (H-De-Start – horizontal start position of port video), 2 (H-De-Total – horizontal active pixels of
port video), 3 (H-Total – total horizontal pixels of port video), 4 (V-De-Start – vertical start position of port
video), 5 (V-De-Total – vertical active lines of port video), 6 (Auto-DE-Adjust – resolution detection mode),
7 (Auto-PHASE-Adjust – phase mode)
channel – input number: 1-32 (varies according to installed input cards, see
Numbering
on page 14)
value – video parameter value in Kramer units:
for all param values: ++ (increase current value), -- (decrease current value)
for 1 (H-De-Start): 1-600
for 2 (H-De-Total): 1-4000
for 3 (H-Total): 1-7000
for 4 (V-De-Start): 1-255
for 5 (V-De-Total): 1-3000
for 6 (Auto-DE-Adjust): 0 (auto), 1 (user defined), 2 (auto adjust)
for 7 (Auto-PHASE-Adjust): 0 (auto), 1 (user defined), 2 (auto adjust)
Response Trigger
Notes
A minus sign precedes negative values.
The auto adjust feature (in the Auto-DE-Adjust and Auto-PHASE-Adjust parameters) requires the
device to recalculate the parameters based on the currently connected source. The result may be
different from the standard parameters for the currently set resolution. The result is saved in non-volatile
memory and is recalled when the same source is used again. In order to revert to auto pre-defined
parameters, either reset to factory setting with the relevant source connected or connect a different
source.
K-Config Example
Set the total horizontal pixels (H-Total parameter) of input 4 to 6000:
"#DETAIL-TIMING 3,4,6000",0x0D
Set the resolution detection mode (Auto-DE-Adjust parameter) of input 4 to auto adjust:
"#DETAIL-TIMING 6,4,2",0x0D
VS-3232DN-EM – Protocol 3000
Permission
End User
End User
Syntax
#DETAIL-TIMINGSPparam,channel,valueCR
#DETAIL-TIMING?SPparam,channelCR
Kramer Electronics Ltd.
Transparency
Public
Public
Port
117
