HUMIDITY:
DIMENSIONS:
PRODUCT WEIGHT:
SHIPPING WEIGHT:
STANDARD COMPLIANCE:
SAFETY REGULATORY COMPLIANCE:
ENVIRONMENTAL REGULATORY
COMPLIANCE:

Defining the DVI-IN4-F32 / DVI-OUT4-F32

The DVI-IN4-F32 is a 4-Input DVI Card (F-32):
The DVI-OUT4-F32 is a 4-Output DVI Card (F-32):
DVI-OUT4-F32 Configuration
The DVI-OUT4-F32 configuration table appears as follows:
DVI-OUT4-F32 Output Card
Parameter Description
Switch When switching between different sources the switching time can be reduced
Speed by setting the fast switch level (Ex-fast Switch, Fast Switch or Normal Switch).
DVI-IN4-F32 / DVI-OUT4-F32 Technical Specifications
The following table defines the technical specifications.
PORTS:
BANDWIDTH PER CHANNEL:
TOTAL BANDWIDTH:
MAXIMUM RANGE:
3D PASS THROUGH:
POWER CONSUMPTION:
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
PRODUCT WEIGHT:
SHIPPING WEIGHT:
STANDARD COMPLIANCE:
VS-3232DN-EM – Using the Input / Output Cards
10% to 90%, RHL non-condensing
22cm x 18.8cm x 2cm (8.7" x 7.4" x 0.8") W, D, H
0.35 kg (0.77 lbs) approx.
0.49 kg (1.08 lbs) approx.
DVI 1.0
CE, FCC
Complies with appropriate requirements of RoHs and
WEEE
4 DVI-D on DVI Molex 24-pin (F) connectors
1.65Gbps
4.95Gbps
15m (49ft)
Not supported
Input / Output card: 3W
0° to +40°C (32° to 104°F)
–40° to +70°C (–40° to 158°F)
10% to 90%, RHL non-condensing
22cm x 18.8cm x 2cm (8.7" x 7.4" x 0.8") W, D, H
0.23 kg (0.51 lbs) approx.
0.37 kg (0.82 lbs) approx.
DVI 1.0
Kramer Electronics Ltd.
Default
Normal
Switch
