Connecting to the VS-3232DN-EM via Ethernet

You can connect to the
•
Directly to the PC using a crossover cable (see
a PC on page 16).
•
Via a network hub, switch, or router, using a straight-through cable (see
Ethernet Port via a Network Hub or Switch
If you want to connect via a router and your IT system is based on IPv6, speak to your IT
department for specific installation instructions.
Connecting the Ethernet Port Directly to a PC
You can connect the Ethernet port of the
PC using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the
VS-3232DN-EM
After connecting the
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
VS-3232DN-EM – Connecting the VS-3232DN-EM
VS-3232DN-EM
with the factory configured default IP address.
VS-3232DN-EM to the Ethernet port, configure your PC as follows:
Figure 7.
Figure 7: Local Area Connection Properties Window
via Ethernet using either of the following methods:
Connecting the Ethernet Port Directly to
on page 18).
VS-3232DN-EM directly to the Ethernet port on your
