MODULE-INFO
Functions
Set -
MODULE-INFO?
Get
Description
Set -
Get
Get module information
Response
~nn@MODULE-INFOSPslot_id,m_direction,channel_start,channel_end,m_type,FW_ver,
upgradable_f,statusCR LF?CR LF
Parameters
slot_id – Module ID (slot number): 0 (control module), 1-16 (I/O cards), 200 (test module),
201 (keyboard software application), 202 (keyboard hardware)
m_direction – Transmission direction: 0 (input), 1 (output), 2 (unknown)
channel_start – Start ID of the port in the device: 1-33
channel_end – End ID of the port in the device: 1-33
m_type – Module type: 0 (DVI), 1 (HDCP), 03 (HDMI), 4 (DL), 09 (F610), 10 (F670), 12 (DGKat),
18 (VGAA), 22 (AAD), 24 (HAA), 25 (HAD), 30 (HDBT), 32 (SDIA), 34 (DT), 41 (UHD), 42 (UHDA),
45 (DTAxr), 47 (control module)
FW_ver – Module firmware version: XX.XX.XXXX where the digit groups are: major.minor.build version
upgradable_f – Indicates whether the firmware can be upgraded: 0 (not upgradable), 1 (upgradable)
status – Module status: 0 (OK), 1 (unknown error), 2 (no communication), 3 (module missing)
Response Trigger
Notes
If m_direction is 2, the channel_start and channel_end values are irrelevant.
K-Config Example
"#MODULE-INFO? 14",0x0D
VS-3232DN-EM – Protocol 3000
Permission
-
End User
Syntax
-
#MODULE-INFO?SPslot_idCR
