3. Press ENT.
The current EDID matrix configuration is displayed. In this example, input 07 is assigned
to output 05, all other EDID values are default.
05 06
Setup Menu—9: Delay, Setting for an Output
This option sets the time delay for an output which lapses between entering a switching action
and the execution of the action. This delay can be set for each output independently. The
delay is defined in units of 200ms and ranges from 0 to 15, providing delays of between 0 and
3 seconds (15 x 200ms = 3 seconds).
To set the execution delay for an output:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 9 (DELAY) on the numeric keypad (see
The output/delay times display is shown.
3. Using the numeric keys, enter the output (in this example, 03).
The following is displayed:
4. Using the numeric keys, enter the number of delay units.
5. Press TAKE.
The selected output delay is set. The display reverts to the output/input display.
Setup Menu—4: store setup XX, Storing the Setup in a Preset
This option stores the current setup in a preset (1 to 60).
To store the current setup in a preset:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 4 (STO) on the numeric keypad (see
The following is displayed:
store => __
3. Using the numeric keys, enter the preset (1 to 60) in which to store the current setup.
The following is displayed:
Wait .....
After a few seconds, if the preset is not empty, the following is displayed:
SETUP NOT EMPTY
CONFIRM
The TAKE button flashes.
VS-3232DN-EM – Using the Configuration Menus
07 08 09 10
05
01 02 03 04 05
Figure 2).
06 07 08
DLY__ =>out03
Figure 2).
