HDCP-STAT
Functions
Set -
HDCP-STAT?
Get
Description
Set -
Get
Get HDCP signal status
Response
~nn@HDCP-STATSPstage,stage_id,statusCR LF
Parameters
stage – 0 (input), 1 (output)
stage_id – input/output number: 1-32 (varies according to installed input/output cards, see
Numbering on page 14)
status – signal encryption status: 0 (HDCP Off), 1 (HDCP On), 2 (Follow input), 3 (Mirror output – MAC
mode)
Response Trigger
Response is sent to the com port from which the Get command was received
Notes
Output stage (1) – get the HDCP signal status of the sink device connected to the specified output
Input stage (0) – get the HDCP signal status of the source device connected to the specified input
K-Config Example
Get the HDCP input signal status of the source device connected to input 9:
"#HDCP-STAT? 0,9",0x0D
VS-3232DN-EM – Protocol 3000
Permission
-
End User
Syntax
-
#HDCP-STAT?SPstage,stage_idCR
Kramer Electronics Ltd.
Transparency
-
Public
Port
105
