Execution is postponed until you confirm the action.
Failure to press the TAKE button within a few seconds results in the action timing out
automatically.
Toggling between the At Once and Confirm Modes
To toggle between the At Once and Confirm modes:
If the TAKE button is flashing you cannot toggle between the At Once and Confirm modes. A
flashing TAKE button indicates that an action is currently pending confirmation.
1. Press TAKE to toggle between the At Once mode and the Confirm mode.
The TAKE button lights and actions now require user confirmation.
2. Press the lit TAKE button to toggle from the Confirm mode back to the At Once mode.
The TAKE button is no longer lit and actions no longer require user confirmation.
Confirming a Switching Action
Actions only require confirmation when the device is in the Confirm mode.
To confirm a switching action:
1. Using the numeric keypad, enter an output-input combination.
The TAKE button flashes.
2. Press the flashing TAKE button to confirm the action.
The action is confirmed and the TAKE button lights.

Switching Actions

This section describes how to:
•
Switch one input to one output (see
•
Switch several inputs to several outputs (see
Outputs on page 22).
•
Turn off several outputs (see
Switching One Input to One Output
To switch one input to one output:
1. Using the numeric keypad, enter the required output (in this example, 12).
The following is displayed:
The left-hand side of the display shows a section of the output/input display
automatically sliding the content to include output 12.
2. Using the numeric keypad, enter the required input (in this example, 14):
VS-3232DN-EM – Operating Your Video Matrix Switcher
Turning an Output Off
06 07 08 09 10
Switching One Input to One Output
Switching Several Inputs to Several
on page 22).
11 12 13
In__ => Out 12
Kramer Electronics Ltd.
on page 21).
21
