The DTAxr-OUT4-F32 configuration table appears as follows:
DTAxr-OUT4-F32 Output Card
Parameter Description
Volume Sets the audio output volume (0–70).
Note: Not applicable when digital audio is selected.
Audio Sets the audio output channel balance (0–100).
Balance
Note: Not applicable when digital audio is selected.
Audio Bass Sets the audio output bass level (0–15).
Note: Not applicable when digital audio is selected.
Audio Sets the audio output treble level (0–15).
Treble
Note: Not applicable when digital audio is selected.
Audio Mute MUTE—Mutes the audio input. Audio is unmuted if any of the audio
parameters are modified.
Non-MUTE—Unmutes the audio input.
Note: Not applicable when digital audio is selected.
Audio Mono OFF—Analog output is stereo.
MIX—Analog output is mono.
Note: Not applicable when digital audio is selected.
ST Sets the direction of the audio port:
0—Audio is set to input
1—Audio is set to output
Note: The direction of the audio signal for each port is indicated by the I/O
LED above the terminal blocks:
ON—Audio is set to input
OFF—Audio is set to output
Switch When switching between different sources the switching time can be
Speed reduced by setting the fast switch level (Fast Switch or Normal Switch).
Reset Re-power: power cycle the port.
Output
Factory default: perform a factory reset of the port to default values.
XTRA Enables range extender. Off for distances of up to 100m at 4K@60Hz 4:2:0
or 4K@30Hz 4:4:4 or 130m at 2K; On for distances of up to 180m at 1080p
@60Hz @24bpp.
*0:ON, 1:OFF, 2:AUTO.
Note: Distances are valid when using Kramer BC-UNIKAT cables.
Audio AUD-Embedded—HDMI audio is selected.
Select
AUD-Ex-Analog—Analog audio from the 16-pin terminal block is selected.
Note: Not applicable when the audio port is set to output (ST=1).
DTAxr-IN4-F32 / DTAxr-OUT4-F32 Technical Specifications
HDBT cards must be used with twisted pair cables with RJ-45 connections, such as Kramer
BC-UNIKAT shielded twisted pair (U/FTP) cables.
The following table defines the technical specifications.
PORTS:
BANDWIDTH PER CHANNEL:
TOTAL BANDWIDTH:
VS-3232DN-EM – Using the Input / Output Cards
4 HDBaseT TP on RJ45 connectors
4 RS-232 Serial ports, 4 IR ports, and 4 analog audio ports on
a 16-pin terminal block
1 Ethernet port on an RJ-45 connector
Video: 3.4Gbps
Serial Data: 115200
Video: 10.2Gbps
Serial Data: 115200
Kramer Electronics Ltd.
Default
50
50
7
7
Non-MUTE
OFF
1
Normal
Switch
Re-power
2
AUD-
Embedded
