4. Press TAKE.
The setup is stored in the selected preset for subsequent recall. The display reverts to
the output/input display.
Setup Menu—6: recall setup XX, Recalling a Preset
This option recalls a stored configuration from a preset (1 to 60).
To recall a stored configuration:
1. Press MENU.
The Setup Menu options are displayed.
2. Press 6 (RCL) on the numeric keypad (see
The following is displayed:
recall <= __
3. Using the numeric keys, enter the preset (in this example, 02) to recall.
The following is displayed:
Wait .....
After a few seconds, the following is displayed on the right-hand side:
CONFIRM
RECALL <= 02
The TAKE button flashes.
4. Press TAKE.
The preset is recalled. The display reverts to the output/input display.

Using the Config Menu

The Config Menu provides access to configuration settings that are not regularly changed and
comprises the following options:
•
Input signal detection display
Display on page 29).
•
Input port parameter setting
•
Output load detection display (see
Display on page 31).
•
Output port parameter setting
Parameters
•
Storing the default setup
•
Total matrix reset
•
Display firmware versions
To enter the Config Menu:
•
Press MENU twice. The MENU button lights and the following message is displayed:
Start configuration menu
MENU to view setups ENT to change them
VS-3232DN-EM – Using the Configuration Menus
(Config Menu—Input Signal Detection
(Config Menu—Setting Input Port Parameters
(Config Menu—Setting Output Port
on page 31).
(Config Menu—Store Default Setup
(Config Menu—Total Matrix Reset
(Config Menu—Display Firmware Versions
Figure 2).
Config Menu—Output Load Detection
on page 33).
Kramer Electronics Ltd.
on page 29).
on page 32).
on page 33).
