Operating Your Video Matrix Switcher

This section describes:
•
The startup display (see
•
Using the selector buttons (see
•
Confirming actions (see
•
Switching options (see
•
Locking the front panel (see
7.1

Startup Display

After switching on the power, the LCD display shows the following screens in
sequence.
The text in the LCD Display may vary (according to machine settings)

Figure 9: Default Startup Status Display Sequence

The front panel of the VS-3232DN includes a numeric keypad within the selector
buttons area. This keypad lets you enter both the output and input numbers as
well as various numeric configuration values (see
18
Section 7.1 )
Section 7.2
Section 7.3 )
Section 7.4 )
Section 7.5 )
VS-3232DN - Operating Your Video Matrix Switcher
)
Section 7.2 ).
