GEDID-EXT
Functions
GEDID-EXT
Set
Get -
Description
Read EDID data from external device connected to an
Set output
Get -
Response
Multi-line response:
~nn@GEDID-EXTSPout_id,sizeCR LF
EDID_dataCR LF
~nn@GEDID-EXTSPout_idSPOKCR LF
Parameters
out_id – Output port EEPROM ID from which to get the EDID: 1-32 (varies according to installed output
cards, see Port Numbering
size – EDID data size sent from the device
Edid_data – EDID data, as byte stream)
Response Trigger
Response is sent to the com port from which the Set (before execution) command was received
Notes
K-Config Example
Read EDID data from a device connected to Output 5:
"#GEDID-EXT 5",0x0D
HDCP-MOD
Functions
HDCP-MOD
Set
HDCP-MOD?
Get
Description
Set HDCP mode
Set
Get
Get HDCP mode
Response
Set / Get: ~nn@HDCP-MODSPinp_id,modeCR LF
Parameters
inp_id – input number: 1-32 (varies according to installed input cards, see
mode – HDCP mode: 0 (HDCP Off), 1 (HDCP On), 2 (Follow input), 3 (Mirror output – MAC mode)
Response Trigger
A response is sent to the com port from which the set (before execution) / get command was received
A response is sent to all com ports after command execution if HDCP-MOD was set by any other external
control device (device button, device menu or other) or if the HDCP mode changed
Notes
Set HDCP working mode on the device input:
HDCP not supported - HDCP Off
HDCP support changes following detected sink - MIRROR OUTPUT
K-Config Example
Disable HDCP mode on input 3:
"#HDCP-MOD 3,0",0x0D
VS-3232DN-EM – Protocol 3000
on page 14)
Permission
Administrator
End User
Syntax
#HDCP-MODSPinp_id,modeCR
#HDCP-MOD?SPinp_idCR
Kramer Electronics Ltd.
Permission Transparency
End User Public
- -
Syntax
#GEDIDSPout_idCR
-
Transparency
Public
Public
Port Numbering on page 14)
