Getting Started - Kramer VS-3232DN-EM User Manual

•
F610-IN4-F32 / F610-OUT4-F32
(see Defining the F610-IN4-F32 / F610-OUT4-F32
•
DVI-IN4-F32 / DVI-OUT4-F32
(see Defining the DVI-IN4-F32 / DVI-OUT4-F32
•
DL-IN2-F32 / DL-OUT2-F32
(see Defining the DL-IN2-F32 / DL-OUT2-F32
•
SDIA-IN4-F32
(see Defining the SDIA-IN4-F32
•
VGAA-IN4-F32 / VGAA-OUT4-F32
(see Defining the VGAA-IN4-F32 / VGAA-OUT4-F32
•
AAD-IN4-F32 / AAD-OUT4-F32
(see Defining the AAD-IN4-F32 / AAD-OUT4-F32
The F670-IN4/OUT4-F32 cards are fully compatible with the Kramer 670T/670R and
671T/671R HDMI/DVI transmitters and receivers for non-HDCP content.

Getting Started

We recommend that you:
•
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
•
Review the contents of this user manual.
Go to www.kramerav.com/downloads/VS-3232DN-EM
application programs, and to check if firmware upgrades are available (where appropriate).
Achieving the Best Performance
To achieve the best performance:
•
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
•
Do not secure the cables in tight bundles or roll the slack into tight coils.
•
Avoid interference from neighboring electrical appliances that may adversely influence
signal quality.
•
Position your
VS-3232DN-EM – Introduction
on page 61).
VS-3232DN-EM away from moisture, excessive sunlight and dust.
on page 58).
on page 59).
on page 60).
on page 62).
on page 64).
to check for up-to-date user manuals,
Kramer Electronics Ltd.
2
