Kramer VS-3232DN-EM User Manual page 115

PRST-STO
Functions
PRST-STO
Set
Get -
Description
Store current connections, volumes and modes as a
Set preset
Get -
Response
~nn@PRST-STOSPpresetCR LF
Parameters
preset – preset number: 1-60
Response Trigger
Notes
In most units, video and audio presets with the same number are stored and recalled together by
commands #PRST-STO and #PRST-RCL
K-Config Example
Store the current connections, volumes, and modes (audio and video routing table) to preset 8:
"#PRST-STO 8",0x0D
PRST-VID
Functions
Set -
PRST-VID?
Get
Description
Set -
Get
Get video connections from saved preset
Response
~nn@PRST-VIDSPpreset,in>outCR LF
or
~nn@PRST-VIDSPpreset,in>1,in>2,in>3,...CR LF
Parameters
preset – preset number: 1-60
in – input number: 0 (if output disconnected), 1-32 (varies according to installed input cards, see
Numbering on page 14)
> - connection character between in and out parameters
out – output number: 1-32 (varies according to installed output cards, see
* (all outputs)
Response Trigger
Notes
In most units, video and audio presets with the same number are stored and recalled together by
commands #PRST-STO and #PRST-RCL
K-Config Example
Get the source of video output 2 from preset 3:
"#PRST-VID? 3,2",0x0D
VS-3232DN-EM – Protocol 3000
Permission
End User
-
Syntax
#PRST-STOSPpresetCR
-
Permission Transparency
- -
End User Public
Syntax
-
#PRST-VID?SPpreset,outCR
#PRST-VID?SPpreset,*CR
Port Numbering
Kramer Electronics Ltd.
Transparency
Public
-
Port
on page 14),
112
