1. Keep a distance of 100cm from the front of the UPS for maintenance and ventilation.
2. Keep a distance of 20cm from the back of the UPS for ventilation.
3. Keep a distance of 45cm from the top of the UPS for wiring, maintenance and
ventilation.
Keep the installation area clean. Please note that wiring routes must be hermetic to pre-
vent possible damage from rodents.
Keep the installation area's temperature around 25°C and humidity below 95%. The
highest operating altitude is 1000 meters above sea level.
For safety concerns, we suggest that you:
1. Equip surroundings of the installation area with CO
personnel to keep the UPS key.
5.3

UPS Transportation

At the bottom of the UPS, there are six
casters to help you to move the UPS to
a designated area. Before you move the
UPS, please turn the four leveling feet
counterclockwise to raise them off the
ground. This protects the leveling feet
from damage when moving the UPS.
Please use sufficient manpower (at least
six people) and equipment (e.g. forklift) to
carefully move the UPS from its pallet to
ground. Please pay attention to the move-
ment of the casters to avoid accidents.
NOTE:
1. The UPS is fixed on the pallet with two balance supports. When taking
2. Please refer to the Unpacking Guide attached to the UPS external wooden
WARNING:
Do not use air conditioners or similar equipment to blow into the
rear of the UPS and hinder ventilation.
apart the two balance supports from the UPS, please pay attention to the
movement of the casters to avoid accidents.
box for location of the balance supports.
2
(Figure 5-1: UPS Leveling Foot and Caster)
5-3
5 Installation and Wiring
Caster Leveling Foot
