Delta Modulon DPH Series User Manual page 15

No.
UPS
1
installed on the inner side of the UPS front
door before shipment)
User Manual
2
Key
3
RS-232 Cable (1.8 meters)
4
Parallel Cable (3 meters)
5
USB Cable
6
7 Test Report
M8 Screw (used for input/ bypass/ output/
8
battery/ grounding wiring)
4-Pin Dry Contact Terminal Block
(used for REPO dry contacts; please refer to
9
Figure 4-3)
6-Pin Dry Contact Terminal Block
(used for MODBUS and BMS ports located
10
at the rear of the touch panel; please refer to
Figure 4-15)
8-Pin Dry Contact Terminal Block
(used for (1) external battery temperature dry
11
contacts and (2) external switch/ breaker status
dry contacts; please refer to Figure 4-3)
10-Pin Dry Contact Terminal Block
(used for input and output dry contacts; please
12
refer to Figure 4-3)
4. If there is any damage or anything missing, please immediately contact the dealer
from whom you purchased the unit.
5. If the UPS needs to be returned, carefully repack the UPS and all of the accessories
using the original packing material that came with the unit.
Item
2-3
2 Introduction
Q'ty
1 PC
1 PC
1 PC (two copies placed
inside the UPS cabinet)
1 PC
1 PC
1 PC
1 PC
18 PCS
1 PC
1 PC
2 PCS
2 PCS
