STS Module

The hot swappable STS module has been installed inside the UPS in the Delta factory
before shipment. Please see the following for its location (see Figure 5-24).
(UPS Front View with Door Open)
B A
GND B A GND
RESET BMS
MODBUS
STS Module
(Figure 5-24: STS Module Location)
For STS module illustration, please refer to Figure 5-25.
LED Indicator
Handle
Handle
Switch
(Figure 5-25: STS Module)
