About 20 seconds after the LCD initial screen is on, the Main Screen will appear
(see Figure 7-4). After you see the Main Screen, you can operate the LCD. Please
note that the Main Screen appears in the User
below.
System Status
7.3

ON/ OFF Button

After the touch panel is turned on in accordance with the steps stated in 7.2 How to Turn
on the LCD, the main screen will appear in the User login status and the ON/ OFF Button
( ) will appear shown in Figure 7-5.
Modulon DPH Series
(Figure 7-3: LCD Initial Screen)
UPS-1.1 MEASUREMENT SETUP
Power Flow
POWER FLOW
Maintenance
Power Flow
Bypass
Bypass
Summary
Mains
90 %
5 mins
(Figure 7-4: Main Screen_ User Login)
User Login
MAINTENANCE LOG IN EVENT LOG
User
7-4
10:15
May 25,2018
Bypass
Load
30 %
