Delta Modulon DPH Series User Manual page 138

11 Press the ON/ OFF button (
if you want to power on the inverter. Please select 'YES'.
12
After selection of 'YES' to start up the inverter, each power module will start up
and perform self-inspection. After the self-inspection is completed, the UPS will
automatically transfer to run in frequency conversion mode and the output frequency
will be the same as setup value. Now, the tri-color LED indicator illuminates green and
the following screen appears. For the tri-color LED indicator location, please refer to
Figure 2-11.
Power Flow
Power Flow
System Status
Modulon DPH Series
UPS-1.1 MEASUREMENT SETUP
Power Flow
(Figure 6-31: Power On Reminder Screen)
UPS-1.1 MEASUREMENT SETUP
POWER FLOW
Maintenance
Bypass
Bypass
Summary
Mains
90 %
5 mins
(Figure 6-32: Frequency Conversion Mode Screen)
) once and the following screen will pop up to ask you
MAINTENANCE LOG IN
Administrator
POWER ON ?
No
Yes
MAINTENANCE LOG IN
Administrator
6-24
10:15
May 25,2018
EVENT LOG
Standby
10:15
May 25,2018
Frequency
EVENT LOG
Conversion
Load
30 %
