5.9.4 Battery Module's LED Indicator

The battery module's LED indicator is located at the front (see Figure 5-54). After a layer
of battery module slot is fully installed four battery modules and the cover of the battery
module slot is installed, you will see the four battery modules' LED indicators from the cover
shown in Figure 5-55.
A GND B A
GND B
BMS
MODBUS
Battery Module's Handle
(Figure 5-53: Remove the Battery Module)
Battery Module
LED Indicator
(Figure 5-54: Battery Module's LED Indicator)
5-43
5 Installation and Wiring
