Delta Modulon DPH Series User Manual page 146

Three phase 15-60 kva 208vac
Hide thumbs Also See for Modulon DPH Series:
Table of Contents

Advertisement

1
In online mode, the LCD shows the following screen and the tri-color LED indicator
illuminates green. For the tri-color LED indicator location, please refer to Figure 2-11.
Power Flow
System Status
(Figure 6-45: Online Mode Screen_ User Login & ON/ OFF Button Location)
2
Press the ON/ OFF button (
normal or not. If normal, please select 'YES'.
Modulon DPH Series
WARNING:
1. For parallel units, ensure that every operation procedure mentioned below is
simultaneously executed and performed to all of the parallel UPSs.
parallel ones, please contact service personnel.
UPS-1.1
MEASUREMENT
SETUP
Power Flow
POWER FLOW
Maintenance
Bypass
Bypass
Summary
Mains
90 %
5 mins
UPS-1.1
MEASUREMENT
SETUP
Power Flow
Transfer to Bypass without Protection!
MAINTENANCE
LOG IN
User
) once and the following screen will pop up to ask you
MAINTENANCE
LOG IN
User
POWER OFF ?
No
Yes
6-32
10:15
May 25,2018
EVENT LOG
On-Line
Load
30 %
10:15
May 25,2018
EVENT LOG
On-Line
ON/ OFF
Button
