Main Menu
Button
MEASUREMENT
SETUP
MAINTENANCE
Modulon DPH Series
Press the button to go to the Measurement Menu. In the menu, you can
check the UPS's readings including the following:
1. Main Input
2. Bypass Input
3. Inverter Output
4. Power Module Summary
5. UPS Output
6. Battery Status
For more information, please refer to 7.9 Check System Readings.
Press the button to go to the Setup Menu. In the menu, you can set up
the following settings.
1. Bypass Setting
2. Mode Setting
3. Output Setting
4. Battery & Charging Setting

5. Parallel Setting

6. Dry Contact Setting

7. General Setting

8. IP Setting

9. Control
For more information, please refer to 7.10 UPS Settings.
Press the button to go to the Maintenance Menu. In the menu, you
can (1) check the warning events/ historical events/ statistics/ relevant
test, (3) clear the statistics/ historical event/ battery test result, and (4)
In the Maintenance Menu, it includes the following items.
1. Warning

2. Historical Event

3. Statistics

4. Test

5. Clear

6. Advanced Diagnosis

7. Version & S/N
For more information, please refer to 7.11 System Maintenance.
NOTE:
screens, inspection items and setup items. Please refer to 7.1 LCD Display
Hierarchy.
Description
7-16
