Item
Battery Type
Battery Rating Voltage
Battery Strings
Battery Low Warning
Capacity
Float Charge Voltage
Equalized Charge
Voltage
Charge Current (Max.)
Auto Equalized Charge
Auto Equalized
Charge Interval
Auto Equalized
Charge Time
Battery Test Fail Voltage
Battery Test Duration
Auto Battery
Test Interval
Low Temperature Alarm
High Temperature Alarm
Installation Date
Next Replacement Date
Set up the battery type.
Set up the battery rating voltage.
Set up how many battery strings that are used on site.
Set up the battery low warning voltage.
Set up the battery low voltage. In battery mode, when the
battery low voltage is reached, the battery power will cut
be protected.
Set up the battery capacity.
Set up the equalized charge voltage.
Set up the maximum charge current.
Enable or disable the auto equalized charge.
Set up the auto equalized charge interval.
Set up the auto equalized charge time.
Set up the battery test fail voltage. When the battery
voltage is under the test fail voltage, it means battery fail.
Set up how long the battery test should last.
Set up the battery test interval.
Enable or disable the low temperature alarm. If enabled,
set up the temperature.
Enable or disable the high temperature alarm. If enabled,
set up the temperature.
Record the battery installation date.
Set up the battery replacement date.
7-27
7
LCD Display & Settings
Description
