3
(1) Turn the STS module's switch to the upper position (
4
switch cannot be moved up anymore.

5.7.2 STS Module Removal

1 (1) Turn the STS module's switch to the lower position (
switch cannot be moved down anymore and (3) wait until the STS module's LED
Modulon DPH Series
(Figure 5-28: Fix the STS Module on the UPS)
(Figure 5-29: Turn the STS Module's Switch to the Upper Position
until the Switch Cannot be Moved up Anymore)
NOTE:
procedures.
2. The STS module is heavy (> 21 kg). At least two people are required for
handling.
(Figure 5-30: Turn the STS Module's Switch to the Lower Position
until the Switch Cannot be Moved down Anymore)
5-28
) , (2) confirm that the
