7.10.6 Dry Contact Setting

Route:
SETUP
In the DRY CONTACT SETTING screen shown below, you can set up the event, NO
(normally open) or NC (normally closed) for each of the input and output dry contacts.
Please refer to the table below. Please note that the settings must be carried out by
UPS-1.1
DRY CONTACT SETTING
Input Dry Contact No.
Input Dry Contact 1
Input Dry Contact 2
Input Dry Contact 3
Input Dry Contact 4
Dry Contact Setting
MEASUREMENT
SETUP
Dry Contact Setting
Event
1
None
2
None
3
None
4
None
You can select one of the following
events as the setting for each input dry
contact.
1. None
2. Generator status
3. Battery ground fail
4. External battery breaker detection
MAINTENANCE
LOG IN
EVENT LOG
Administrator
INPUT
OUTPUT
Type
Normally Open
Normally Open
Normally Open
Normally Open
Event Selection
7-29
7
LCD Display & Settings
10:15
May 25,2018
Bypass
Type
You can set up NO
(normally open)
or NC (normally
closed) for each
input dry contact.
