Delta Modulon DPH Series User Manual page 64

P6 (Max. 0.5A/12V)
P5 (Max. 0.5A/12V)
P4 (Max. 0.5A/12V)
P3 (Max. 0.5A/12V)
P2 (Max. 0.5A/12V)
P1 (Max. 0.5A/12V)
No.
1 None
2 Load On Inverter
3 Load On Bypass
4 Load On Battery
Modulon DPH Series
10
112
6
8
2
4
9
11
5
7
1
3
UPS
(Figure 4-9: Output Dry Contacts Design)
Event
No set-up.
The UPS works in online mode.
The UPS works in bypass mode.
When the main AC source fails, the batteries supply
power to the critical loads.
O/P DRY
CONTACT
P1 P2 P3
P4 P5 P6
DRY F_NO
COMM_F
DRY E_NO
COMM_E
DRY D_NO
COMM_D
DRY C_NO
COMM_C
DRY B_NO
COMM_B
DRY A_NO
COMM_A
Description
4-8
+12VS
DRY 6
+12VS
DRY 5
+12VS
DRY 4
+12VS
DRY 3
+12VS
DRY 2
+12VS
DRY 1
