Model DPH
15kVA/ 30kVA/ 45kVA/ 60kVA/
UPS Capacity
15kW 30kW 45kW 60kW
Nominal Voltage
Voltage Range 96 ~ 146Vac (full load)
Current Harmonic
3% * 1
Input
Distortion
Power Factor > 0.99
Frequency Range 40 ~ 70 Hz
Voltage
Voltage Harmonic
2% (linear load)
Distortion
Output Power Factor 1
Frequency 50/60 Hz
125% : 10 minutes ; 150% : 1 minute;
Overload Capability
> 150% : 1 second
Display 10" Touch Panel
External battery temperature dry contact x 4, External
switch/ breaker status dry contact x 4,
Output dry contact x 6, Input dry contact x 4,
Interface Standard
Parallel port x 4, USB type A x 2, USB type B x 1,
RS-232 port x 1,MODBUS port x 1, BMS (RJ45) x 1,
Ethernet x 1, SMART slot x 1, REPO x 1
Online Mode up to 95%
Efficiency
ECO Mode 98%
Nominal Voltage ±168 Vdc
Charge Voltage ±190V (adjustable from 182 Vdc to 196Vdc)
Battery
Protection of Battery
Yes
Deep Discharge
Modulon DPH Series
A1-2
