7.9.5 UPS Output

Route:
MEASUREMENT
In the UPS OUTPUT screen shown below, you can check the Phase Voltage, Line
Voltage, Current, Frequency, Load, Apparent Power, Active Power and Power Factor.
UPS-1.1
UPS OUTPUT
Phase Voltage(V)
Line Voltage(V)
Current(A)
Frequency(Hz)
Load(%)

7.9.6 Battery Status

Route:
MEASUREMENT
In the BATTERY STATUS screen shown below, you can check the Status, Voltage,
Current, Remaining Capacity, Remaining Time, Estimated Recharging Time, Test
Result, Battery Temperature (#1~#4), and each power module's Charge Voltage and
Charge Current.
UPS-1.1
BATTERY STATUS
Status
Voltage(V)
Current(A)
Remaining Capacity (%)
Remaining Time (mins)
Estimated Recharging Time (mins)
UPS Output
MEASUREMENT SETUP MAINTENANCE
UPS Output
120.0 120.0 120.0
208.0 208.0 208.0
41.6 41.6 41.6
60.0
100% 100% 100%
Battery Status
MEASUREMENT SETUP MAINTENANCE
Battery Status
None
+ 190.4
- 190.4
05:00
00:00
LOG IN EVENT LOG
Administrator
Apparent Power(KVA)
Active Power(KW)
Power Factor
LOG IN EVENT LOG
Administrator
PAGE PAGE
1 2
Test Result
Battery Temp. #1 (°C)
Battery Temp. #2 (°C)
+ 0
- 0
Battery Temp. #3 (°C)
90
Battery Temp. #4 (°C)
7-21
7 LCD Display & Settings
10:15
May 25,2018
On-Line
5 5 5
5 5 5
1 1 1
10:15
May 25,2018
On-Line
None
-
-
-
-
